Traction Control Multiplexer (TCMux)

The Traction Control Multiplexer (TCMux) is designed to increase the speed inputs into a MoTeC ECU.

It takes four individual wheel speed signals and turns them into one coded signal for an ECU to read as driven speed (wheels that have power), undriven speed (rolling wheels) and slip (percentage difference between driven and undriven wheels).

Compatible with all MoTeC ECUs

Inputs:

• 4 x Digital/speed inputs

 Communications

• MoTeC specific coded signal supplied to an ECU digital/speed input

 Physical

• Case size 70 x 100 x 35 mm excluding connector
•  Weight 215 gram
•  1 x 18 pin waterproof connector with gold plated contacts
